Switches
Showing 1–40 of 101 results
-
£2,267.98
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 48
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 48 x 10/100/1000 Mbps RJ45 Ports
6 x 10G SFP+ Slots
2 x USB 2.0 Ports
1 x RJ45 Console Port
1 x USB Type-C Console Port
1 x RJ45 Management Port - PoE Ports (RJ45): “Standard: 802.3at/af compliant
PoE+ Ports: 48 Ports, up to 30 W per port
PoE Power Budget: up to 1440 W**The total PoE budget varies with the power supply modules.”
- Bandwidth: Stack Bandwidth: 20 Gbps Per Port (Full-Duplex)
- Switching Capacity: 216 Gbps per Unit
- Power Supply: “Two Field-replaceable and Hot-swappable Power Supply Modules (100–240 VAC, 50/60 Hz)”
- Dimensions: 440 x 420 x 44 mm
- Mac Address Table: 32 K
- Packet Forwarding Rate: 160.7 Mpps
- Jumbo Frame: 9KB
- Additional Features: Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot ScheduleISP Features:
802.3ah Ethernet Link OAM
L2PT (Layer 2 Protocol Tunneling)
Device Link Detect Protocol (DLDP)
DDM
sFlow - Quality of Service: Class of Service
Bandwidth Control
Voice VLAN
User-Defined OUI
Smoother Performance
Action for Flows - Layer Features: “L3:
IP Interfaces: IPv4: Max 256, IPv6: Max 256
Static Routing
Host Route Table
RIP
OSPF
VRRP
ECMP
Static ARP
Dynamic ARP
Proxy ARP
DHCP Server
DHCP RelayL2 and L2+:
Link Aggregation
Spanning Tree Protocol
Port-based and VLAN-based Loopback Detection
802.3x Flow Control
Supports 2,048 IGMP groups
ERPS
Mirroring
RSPAN
MAC Address Table
PIM-DM (IPv4)
Multicast” - VLAN: “Max 4K VLAN Group (802.1q VLAN)
802.1Q Tagged VLAN
MAC VLAN Entries: 200
Multicast VLAN
Management VLAN
VLAN VPN (QinQ): Max 256 entries
GVRP
Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries
VLAN VPN
Voice VLAN
Private VLAN” - Security: Port Isolation
CPU-Defend
ARP Inspection (Dynamic ARP Inspection)
DoS Defend
IP-MAC-Port Binding
IPv6-MAC
DHCP Filter
Static/Dynamic Port Security
Broadcast/Multicast/Unknown-unicast Storm Control
802.1X
AAA (including TACACS+)
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure Command Line Interface (CLI) management with SSHv2
IP/Port/MAC-based access control - Management: “ Omada App, Centralized Management & Cloud Access :
Requires Omada Hardware, Cloud-Based or Software ControllerZero-Touch Provisioning :
Requires Omada Cloud-Based Controller“
- .: “ Management Features :
Web-based GUI
CLI through console port, telnet
SNMPv1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP Auto Install
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
Password Recovery
SNTP
System Log
EEE” - Environment: Operating Temperature:0°C to 45 °C
Storage Temperature: -40 °C to 70 °C
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: SG6654XHP Switch
Power Cord
RJ45 Console Cable
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 12.1000 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
Out of stock
TP-LINK (SG6654XHP) Omada 48-Port Gigabit Stackable L3 Managed PoE+ Switch with 6x 10G SFP+ Slots, USB
£2,267.98 Read moreQuick View -
£1,579.24
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 48
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 48 x 10/100/1000 Mbps RJ45 Ports
6 x 10G SFP+ Slots
2 x USB 2.0 Ports
1 x RJ45 Console Port
1 x USB Type-C Console Port
1 x RJ45 Management Port - PoE Ports (RJ45): –
- Bandwidth: Stack Bandwidth: Up to 120 Gbps (6 stack ports)
- Switching Capacity: 216 Gbps per Unit
- Power Supply: “Two Internal Fixed Power Supply Modules (100–240 VAC, 50/60 Hz)”
- Dimensions: 440 x 380 x 44 mm
- Mac Address Table: 32 K
- Packet Forwarding Rate: 160.7 Mpps
- Jumbo Frame: 9KB
- Additional Features: Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot ScheduleISP Features:
802.3ah Ethernet Link OAM
L2PT (Layer 2 Protocol Tunneling)
Device Link Detect Protocol (DLDP)
DDM
sFlow - Quality of Service: Class of Service
Bandwidth Control
Voice VLAN
User-Defined OUI
Smoother Performance
Action for Flows - Layer Features: “L3:
IP Interfaces: IPv4: Max 256, IPv6: Max 256
Static Routing
Host Route Table
RIP
OSPF
VRRP
ECMP
Static ARP
Dynamic ARP
Proxy ARP
DHCP Server
DHCP RelayL2 and L2+:
Link Aggregation
Spanning Tree Protocol
Port-based and VLAN-based Loopback Detection
802.3x Flow Control
Supports 2,048 IGMP groups
ERPS
Mirroring
RSPAN
MAC Address Table
PIM-DM (IPv4)
Multicast” - VLAN: “Max 4K VLAN Group (802.1q VLAN)
802.1Q Tagged VLAN
MAC VLAN Entries: 200
Multicast VLAN
Management VLAN
VLAN VPN (QinQ): Max 256 entries
GVRP
Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries
VLAN VPN
Voice VLAN
Private VLAN” - Security: Port Isolation
CPU-Defend
ARP Inspection (Dynamic ARP Inspection)
DoS Defend
IP-MAC-Port Binding
IPv6-MAC
DHCP Filter
Static/Dynamic Port Security
Broadcast/Multicast/Unknown-unicast Storm Control
802.1X
AAA (including TACACS+)
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure Command Line Interface (CLI) management with SSHv2
IP/Port/MAC-based access control - Management: “ Omada App, Centralized Management & Cloud Access :
Requires Omada Hardware, Cloud-Based or Software ControllerZero-Touch Provisioning :
Reques Omada Cloud-Based Controller“
- .: “ Management Features :
Web-based GUI
CLI through console port, telnet
SNMPv1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP Auto Install
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
Password Recovery
SNTP
System Log
EEE” - Environment: “Operating Temperature:
-5 °C to 50 °C (23 °F to 122 °F) @ 300 meters
-5 °C to 45 °C (23 °F to 113 °F) @ 2,000 meters
-5 °C to 40 °C (23 °F to 104 °F) @ 3,000 metersStorage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing” - Package Contents: SG6654X Switch
2x Power Cords
RJ45 Console Cable
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 9.0100 kg
- Warranty: Limited Lifetime
- #Hide#POE: No
Out of stock
TP-LINK (SG6654X) Omada 48-Port Gigabit Stackable L3 Managed Switch with 6x 10G SFP+ Slots, USB
£1,579.24 Read moreQuick View -
£1,182.69
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 24
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 24 x 10/100/1000 Mbps RJ45 Ports
4 x 10G SFP+ Slots
2 x USB 2.0 Ports
1 x RJ45 Console Port
1 x USB Type-C Console Port
1 x RJ45 Management Port - PoE Ports (RJ45): –
- Bandwidth: Stack Bandwidth: Up to 80 Gbps (4 stack ports)
- Switching Capacity: 128 Gbps per Unit
- Power Supply: “Two Internal Fixed Power Supply Modules (100–240 VAC, 50/60 Hz)”
- Dimensions: 440 x 380 x 44 mm
- Mac Address Table: 32 K
- Packet Forwarding Rate: 95.2 Mpps
- Jumbo Frame: 9KB
- Additional Features: Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot ScheduleISP Features:
802.3ah Ethernet Link OAM
L2PT (Layer 2 Protocol Tunneling)
Device Link Detect Protocol (DLDP)
DDM
sFlow - Quality of Service: Class of Service
Bandwidth Control
Voice VLAN
User-Defined OUI
Smoother Performance
Action for Flows - Layer Features: “L3:
IP Interfaces: IPv4: Max 256, IPv6: Max 256
Static Routing
Host Route Table
RIP
OSPF
VRRP
ECMP
Static ARP
Dynamic ARP
Proxy ARP
DHCP Server
DHCP RelayL2 and L2+:
Link Aggregation
Spanning Tree Protocol
Port-based and VLAN-based Loopback Detection
802.3x Flow Control
Supports 2,048 IGMP groups
ERPS
Mirroring
RSPAN
MAC Address Table
PIM-DM (IPv4)
Multicast” - VLAN: “Max 4K VLAN Group (802.1q VLAN)
802.1Q Tagged VLAN
MAC VLAN Entries: 200
Multicast VLAN
Management VLAN
VLAN VPN (QinQ): Max 256 entries
GVRP
Protocol VLAN: Protocol Template 16, Protocol VLAN 12 entries
VLAN VPN
Voice VLAN
Private VLAN” - Security: Port Isolation
CPU-Defend
ARP Inspection (Dynamic ARP Inspection)
DoS Defend
IP-MAC-Port Binding
IPv6-MAC
DHCP Filter
Static/Dynamic Port Security
Broadcast/Multicast/Unknown-unicast Storm Control
802.1X
AAA (including TACACS+)
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure Command Line Interface (CLI) management with SSHv2
IP/Port/MAC-based access control - Management: “ Omada App, Centralized Management & Cloud Access :
Requires Omada Hardware, Cloud-Based or Software ControllerZero-Touch Provisioning :
Reques Omada Cloud-Based Controller“
- .: “ Management Features :
Web-based GUI
CLI through console port, telnet
SNMPv1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP Auto Install
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
Password Recovery
SNTP
System Log
EEE” - Environment: “Operating Temperature:
-5 °C to 50 °C (23 °F to 122 °F) @ 300 meters
-5 °C to 45 °C (23 °F to 113 °F) @ 2,000 meters
-5 °C to 40 °C (23 °F to 104 °F) @ 3,000 metersStorage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing” - Package Contents: SG6428X Switch
2x Power Cords
RJ45 Console Cable
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 8.5800 kg
- Warranty: Limited Lifetime
- #Hide#POE: No
Out of stock
TP-LINK (SG6428X) Omada 24-Port Gigabit Stackable L3 Managed Switch with 4x 10G SFP+ Slots, USB
£1,182.69 Read moreQuick View -
£695.69
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 48
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 48 x 10/100/1000 Mbps RJ45 PoE+ Ports
4 x 10G SFP+ Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): “Standard: 802.3at/af compliant
PoE+ Ports: 48 Ports, up to 30 W per port
Power Budget: 500 W” - Switching Capacity: 176 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
Consumption:
49.19 W (110V/60Hz) (no PD device connected)
635.7 W (110V/60Hz) (with 500 W PD device connected) - Dimensions: (WxDxH) 440 x 330 x 44 mm
- Mac Address Table: 16 K
- Packet Forwarding Rate: 130.9 Mpps
- Jumbo Frame: 9 KB
- Additional Features: Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule - Quality of Service: 8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
Bandwidth Contro
Smoother Performance
Action for Flows - Layer Features: L2 and L2+ Features
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
MirroringL2 Multicast
IGMP Snooping
IGMP Authentication
MLD Snooping
MVR
Multicast Filtering: 256 profiles and 16 entries per profile - VLAN: “VLAN Group
802.1Q Tagged VLAN
MAC VLAN: 30 Entries
Protocol VLAN: Protocol Template 16, Protocol VLAN 16
Private VLAN
GVRP
VLAN VPN (QinQ)
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure Command Line Interface (CLI) management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Omada App
Centralized Management
Cloud Access
Zero-Touch ProvisioningManagement Features:
Web-based GUI
Command Line Interface (CLI) through the console port, telnet
SNMP v1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: Operating Temperature: 0–40°C (32–104°F)
Storage Temperature: -40–70°C (-40–158°F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: TL-SG3452XP Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 6.6000 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
14 in stock
TP-LINK (TL-SG3452XP) JetStream 48-Port Gigabit and 4-Port 10GE SFP+ L2+ Managed Switch with 48-Port PoE+, Rackmountable
£695.69 Add to basketQuick View -
£640.04
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 24
- Max RJ45 Transfer Rate: 2.5 Gbps
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 24 x 2.5 Gbps RJ45 Ports
4 x 10G SFP+ Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): “Standard: 802.3bt/at/af compliant
PoE++ Ports(802.3bt PoE): 8 Ports, up to 60 W per port
PoE+ Ports(802.3at PoE): 16 Ports, up to 30 W per port
Power Budget: 500 W” - Switching Capacity: 200 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
- Dimensions: (WxDxH) 440 x 330 x 44 mm
- Mac Address Table: 32 K
- Packet Forwarding Rate: 148.80 Mpps
- Jumbo Frame: 9 KB
- Additional Features: Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule - Quality of Service: 8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
Bandwidth Control
Smoother Performance
Action for Flows - Layer Features: L2 and L2+:
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
MirroringL2 Multicast:
IGMP Snooping
IGMP Authentication
MLD Snooping
MVR
Multicast Filtering: 256 profiles and 16 entries per profileL3:
32 IPv4/IPv6 Interfaces
Static Routing
Static ARP
Proxy ARP
Gratuitous ARP
DHCP Server
DHCP Relay
DHCP L2 Relay - VLAN: “VLAN Group
802.1Q Tagged VLAN
MAC VLAN: 256 Entries
Protocol VLAN: Protocol Template 16, Protocol VLAN 16
GVRP
VLAN VPN (QinQ)
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure Command Line Interface (CLI) management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Require Omada Controllers:
Omada App
Centralized Management
Cloud Access
Zero-Touch ProvisioningManagement Features:
Web-based GUI
Command Line Interface (CLI) through the console port, telnet
SNMP v1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: Operating Temperature: 0–40°C (32–104°F)
Storage Temperature: -40–70°C (-40–158°F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: TL-SG3428XPP-M2 Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 6.1000 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
Out of stock
TP-LINK (TL-SG3428XPP-M2) JetStream 24-Port 2.5GBASE-T & 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ & 8-Port PoE++, Rackmountable
£640.04 Read moreQuick View -
£584.38
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 52
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 48 x 10/100/1000 Mbps RJ45 Ports
4 x Gigabit SFP Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): “Standard: 802.3at/af compliant
PoE+ Ports: 48 Ports, up to 30 W per port
Power Budget: 384 W” - Switching Capacity: 104 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
Power Consumption:
52.53 W (110 V/60 Hz) (no PD connected)
485.4 W (110 V/60 Hz) (with 384 W PD connected) - Dimensions: 440 x 330 x 44 mm
- Mac Address Table: 16 K
- Packet Forwarding Rate: 77.4 Mpps
- Jumbo Frame: 9 KB
- Additional Features: “Support Omada Hardware, Software, Cloud-Based Controller
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
ZTP (Zero-Touch Provisioning)” - Quality of Service: 8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
Bandwidth Control
Smoother Performance
Action for Flows - Layer Features: L2 and L2+
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
MirroringL3
16 IPv4/IPv6 Interfaces
Static Routing
Static ARP
316 ARP Entries
Proxy ARP
Gratuitous ARP
DHCP Server
DHCP Relay
DHCP L2 Relay - VLAN: “VLAN Group
802.1q Tagged VLAN
MAC VLAN: 12 Entries
Protocol VLAN: Template 16, VLAN 16
GVRP
VLAN VPN (QinQ)
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
IP/Port/MAC based access control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management – HTTPS with SSLv3/TLS 1.2
Secure CLI management with SSHv1/SSHv2 - Management: “Web-based GUI
CLI through console port, telnet
SNMPv1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: “Operating Temperature: 0C~45C (32F~113F);
Storage Temperature: -40C~70C (-40F~158F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing” - Package Contents: TL-SG3452P Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 7.0000 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
5 in stock
TP-LINK (TL-SG3452P) JetStream 52-Port Gigabit L2+ Managed Switch with 48-Port PoE+, 4 SFP Slots, Rackmountable
£584.38 Add to basketQuick View -
£556.56
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 6
- Max RJ45 Transfer Rate: 10 Gbps
- Interface(s): 4 x 100/1000/2500/5000/10000 Mbps RJ45 Ports
2 x 10G SFP+ Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): “Standard: 802.3bt/at/af compliant
PoE+ Ports: 4 Ports, up to 60 W per port
Power Budget: 200 W” - Switching Capacity: 120 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
- Dimensions: (WxDxH) 294 x 180 x 44 mm
- Mac Address Table: 32 K
- Packet Forwarding Rate: 89.28 Mpps
- Jumbo Frame: 9 KB
- Additional Features: “Support Omada Hardware (OC200/OC300), Software & Cloud-Based Controller
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
ZTP (Zero-Touch Provisioning)” - Quality of Service: 8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
Bandwidth Control
Smoother Performance
Action for Flows - Layer Features: L2 and L2+:
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
MirroringL2 Multicast:
IGMP Snooping
IGMP Authentication
MLD Snooping
MVR
Multicast Filtering: 256 profiles and 16 entries per profileL3:
16 IPv4/IPv6 Interfaces
Static Routing
Static ARP
Proxy ARP
Gratuitous ARP
DHCP Server
DHCP Relay
DHCP L2 Relay - VLAN: “VLAN Group
802.1Q Tagged VLAN
MAC VLAN: 10 Entries
Protocol VLAN: Protocol Template 16, Protocol VLAN 16
Private VLAN
GVRP
VLAN VPN (QinQ)
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure CLI management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Web-based GUI
CLI through the console port, telnet
SNMP v1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: Operating Temperature: 0–50°C (32–122°F)
Storage Temperature: -40–70°C (-40–158°F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: TL-SX3206HPP Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 2.6400 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
Out of stock
TP-LINK (TL-SX3206HPP) JetStream 6-Port 10GE L2+ Managed Switch with 4-Port PoE++, Rackmountable
£556.56 Read moreQuick View -
£486.98
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 16
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 16 x 10GE SFP+ Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): –
- Switching Capacity: 320 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
Max Power Consumption: 32.74 W (220 V / 50 Hz)
- Dimensions: (WxDxH) 440 x 220 x 44 mm
- Mac Address Table: 32 K
- Packet Forwarding Rate: 238.08 Mpps
- Jumbo Frame: 9 KB
- Additional Features: “Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
ZTP (Zero-Touch Provisioning)
Support Omada Hardware Controller (OC200/OC300), Software Controller, Cloud-Based Controller” - Quality of Service: 8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
Bandwidth Control
Smoother Performance
Action for Flows - Layer Features: L2 and L2+ Features
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
MirroringL2 Multicast
IGMP Snooping
IGMP Authentication
MLD Snooping
MVR
Multicast Filtering: 256 profiles and 16 entries per profile - VLAN: “VLAN Group
802.1Q Tagged VLAN
MAC VLAN: 30 Entries
Protocol VLAN: Protocol Template 16, Protocol VLAN 16
Private VLAN
GVRP
VLAN VPN (QinQ)
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure Command Line Interface (CLI) management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Web-based GUI
SNMP v1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log
Command Line Interface (CLI) through the console port, telnet” - Environment: “Operating Temperature: 0–45 °C (32–113 °F);
Storage Temperature: -40–70 °C (-40–158 °F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing” - Package Contents: TL-SX3016F Switch
2 x Power Cords
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 4.0000 kg
- Warranty: Limited Lifetime
- #Hide#POE: No
3 in stock
TP-LINK (TL-SX3016F) JetStream 16-Port 10GE SFP+ L2+ Managed Switch, Centralized Management, Dual Redundant PSUs, Rackmountable
£486.98 Add to basketQuick View -
£471.69
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 48
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 48 x 10/100/1000 Mbps RJ45 Ports
4 x 10G SFP+ Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - Switching Capacity: 176 Gbps
- Power Supply: Power Supply
100-240 V AC~50/60 HzMax Power Consumption
32.72 W (110V/60Hz) - Dimensions: (WxDxH) 440 x 220 x 44 mm
- Mac Address Table: 16 K
- Packet Forwarding Rate: 130.9 Mpps
- Jumbo Frame: 9 KB
- Additional Features: Supports Omada Hardware/Software/Cloud-Based Controller
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
ZTP (Zero-Touch Provisioning) - Quality of Service: L2/L3/L4 QoS
- Layer Features: “L2 and L2+ Features
Link Aggregation
Static link aggregation
802.3ad LACP
Up to 8 aggregation groups, containing 8 ports per group
Spanning Tree Protocol
802.1d STP
802.1w RSTP
802.1s MSTP
STP Security: TC Protect, BPDU Filter, Root Protect
Loopback Detection
Port based
VLAN based
Flow Control
802.3x Flow Control
HOL Blocking Prevention
Mirroring
Port Mirroring
CPU Mirroring
One-to-One
Many-to-One
Tx/Rx/Both” - VLAN: “VLAN Group
Max 4K VLAN Groups
802.1Q Tagged VLAN
MAC VLAN: 30 Entries
Protocol VLAN: Protocol Template 16, Protocol VLAN 16
Private VLAN
GVRP
VLAN VPN (QinQ)
Port-Based QinQ
Selective QinQ
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
Source MAC
Destination MAC
VLAN ID
User Priority
Ether Type
IP ACL
Source IP
Destination IP
Fragment
IP Protocol
TCP Flag
TCP/UDP Port
DSCP/IP TOS
User Priority
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
Mirroring
Redirect
Rate Limit
QoS Remark
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure Command Line Interface (CLI) management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Web-based GUI
Command Line Interface (CLI) through the console port, telnet
SNMP v1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: “Operating Temperature: 0–45°C (32–113°F);
Storage Temperature: -40–70°C (-40–158°F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing” - Package Contents: TL-SG3452X Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 3.9500 kg
- Warranty: Limited Lifetime
- #Hide#POE: No
Out of stock
TP-LINK (TL-SG3452X) JetStream 48-Port Gigabit L2+ Managed Switch with 10GE 4 SFP+ Slots, L2/L3/L4 QoS, Fanless, Rackmountable
£471.69 Read moreQuick View -
£471.69
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 24
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 20 x Gigabit SFP Ports
4 x Gigabit SFP/RJ45 Combo Ports
4 x 10G SFP+ Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): –
- Switching Capacity: 128 Gbps
- Power Supply: Dual Reduant Power Supplies
100-240 V AC~50/60 Hz - Dimensions: 440 x 220 x 44 mm
- Mac Address Table: 16 K
- Packet Forwarding Rate: 95.23 Mpps
- Jumbo Frame: 9 KB
- Additional Features: Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule - Quality of Service: 8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
Bandwidth Control
Smoother Performance
Action for Flows - Layer Features: L2 and L2+ Features
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
MirroringL2 Multicast
IGMP Snooping
IGMP Authentication
MLD Snooping
MVR
Multicast Filtering: 256 profiles and 16 entries per profile - VLAN: “VLAN Group – Max 4K
802.1Q Tagged VLAN
MAC VLAN: 30 Entries
Protocol VLAN: Protocol Template 16, Protocol VLAN 16
Private VLAN
GVRP
VLAN VPN (QinQ)
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure Command Line Interface (CLI) management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Omada App*
Centralized Management*
Cloud Access**Requires OC300, OC200, Cloud-Based/Software Controller
Management Features:
Web-based GUI
Command Line Interface through the console port, telnet
SNMP v1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: “Operating Temperature: 0–45 °C (32–113 °F);
Storage Temperature: -40–70 °C (-40–158 °F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing” - Package Contents: TL-SG3428XF Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 4.4500 kg
- Warranty: Limited Lifetime
- #Hide#POE: No
4 in stock
TP-LINK (TL-SG3428XF) JetStream 24-Port SFP L2+ Managed Switch w/ 4 10GE SFP+ Slots, Dual Redundant PSUs, Rackmountable
£471.69 Add to basketQuick View -
£459.16
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 24
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 24 x 10/100/1000 Mbps RJ45 Ports
4 x 10G SFP+ Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): 24 x 802.3at/af-compliant PoE+ ports with a total power supply of 384 W
- Switching Capacity: 128 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
Consumption:
34.4 W (110V/60Hz) ( no PD device connected)
465.8 W (110V/60Hz) ( with 384 W PD device connected) - Dimensions: 440 x 330 x 44 mm
- Mac Address Table: 16 K
- Packet Forwarding Rate: 95.23 Mpps
- Jumbo Frame: 9 KB
- Additional Features: “Support Omada Hardware Controller, Software Controller, Cloud-Based Controller
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
ZTP (Zero-Touch Provisioning)” - Quality of Service: 8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
Bandwidth Control
Smoother Performance
Action for Flows - Layer Features: L2 and L2+ Features
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
MirroringL2 Multicast
IGMP Snooping
IGMP Authentication
MLD Snooping
MVR
Multicast Filtering: 256 profiles and 16 entries per profileL3 Features
16 IPv4/IPv6 Interfaces
Static Routing
Static ARP
Proxy ARP
Gratuitous ARP
DHCP Server
DHCP Relay
DHCP L2 Relay - VLAN: “VLAN Group
802.1Q Tagged VLAN
MAC VLAN: 7 Entries
Private VLAN
GVRP
VLAN VPN (QinQ)
Voice VLAN
Protocol VLAN: Protocol Template 16, Protocol VLAN 16″ - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management – HTTPS with SSLv3/TLS 1.2
Secure CLI management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Web-based GUI
CLI through the console port, telnet
SNMP v1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: “Operating Temperature: 0C~45C (32F~113F);
Storage Temperature: -40C~70C (-40F~158F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing” - Package Contents: TL-SG3428XMP Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 6.2000 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
10 in stock
TP-LINK (TL-SG3428XMP) JetStream 24-Port Gigabit & 4-Port 10GE SFP+ L2+ Managed Switch with 24-Port PoE+, Rackmountable
£459.16 Add to basketQuick View -
£417.42
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 28
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 24 x 10/100/1000Mbps RJ45 Ports
4 x Gigabit SFP Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): “Standard: 802.3at/af compliant
PoE+ Ports: 24 Ports, up to 30 W
Power Supply: 384 W” - Switching Capacity: 56 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
- Dimensions: 440 x 180 x 44 mm
- Mac Address Table: 8K
- Packet Forwarding Rate: 41.66 Mpps
- Jumbo Frame: 9 KB
- Additional Features: Support Omada Hardware Controller
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
ZTP (Zero-Touch Provisioning) - Quality of Service: 8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
Bandwidth Control
Port/Flow based Rating Limiting
Smoother Performance
Action for Flows - Layer Features: “Link Aggregation
Spanning Tree Protocol
Protect, Root Protect, Loop Protect
Loopback Detection
Flow Control
Mirroring
L2 Multicast
Supports 511 (IPv4, IPv6) IGMP groups
IGMP Snooping
IGMP Authentication
MVR
MLD Snooping
Multicast Filtering” - VLAN: “VLAN Group
802.1q Tagged VLAN
MAC VLAN: 12 Entries
GVRP
VLAN VPN (QinQ)
Voice VLAN
Protocol VLAN: Protocol Template 16, Protocol VLAN 16″ - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
IP/Port/MAC based access control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure CLI management with SSHv1/SSHv2 - Management: “Web-based GUI
CLI through console port, telnet
SNMPv1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: “Operating Temperature: 0C~45C (32F~113F);
Storage Temperature: -40C~70C (-40F~158F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing” - Package Contents: Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 6.2000 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
7 in stock
TP-LINK (TL-SG3428MP) JetStream 28-Port Gigabit L2 Managed Switch with 24-Port PoE+, 4 SFP Slots, Rackmountable
£417.42 Add to basketQuick View -
£396.55
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 16
- Max RJ45 Transfer Rate: 2.5 Gbps
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 16 x 2.5 Gbps RJ45 Ports
2 x 10G SFP+ Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): “Standard: 802.3at/af compliant
PoE+ Ports(802.3at PoE): 8 Ports, up to 30 W per port
Power Budget: 240 W” - Switching Capacity: 120 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
Max Power Consumption: 299.4 W (110V/60Hz)(with 240 W PD connected) - Dimensions: (WxDxH) 440 x 180 x 44 mm
- Mac Address Table: 16 K
- Packet Forwarding Rate: 89.28 Mpps
- Jumbo Frame: 9 KB
- Additional Features: Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule - Quality of Service: “8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
Bandwidth Control
Smoother Performance
Action for Flows: QoS remark (802.1P Remark, DSCP Remark)” - Layer Features: L3 Features
32 IPv4/IPv6 Interfaces
Static Routing
Static ARP
Proxy ARP
Gratuitous ARP
DHCP Server
DHCP Relay
DHCP L2 RelayL2 and L2+ Features
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
Mirroring - .: L2 Multicast
IGMP Snooping
IGMP Authentication
MLD Snooping
MVR
Multicast Filtering: 256 profiles and 16 entries per profile - VLAN: “VLAN Group
802.1Q Tagged VLAN
MAC VLAN: 256 Entries
Protocol VLAN: Protocol Template 16, Protocol VLAN 16
GVRP
VLAN VPN (QinQ)
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure Command Line Interface (CLI) management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Omada App
Centralized Management
Cloud Access
Zero-Touch ProvisioningManagement Features:
Web-based GUI
CLI through the console port, telnet
SNMP v1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: Operating Temperature: 0–50°C (32–122°F)
Storage Temperature: -40–70°C (-40–158°F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: SG3218XP-M2 Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 3.1900 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
4 in stock
TP-LINK (SG3218XP-M2) Omada 16-Port 2.5G and 2-Port 10GE SFP+ L2+ Managed Switch with 8-Port PoE+, Rackmountable
£396.55 Add to basketQuick View -
£347.85
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 8
- Max RJ45 Transfer Rate: 2.5 Gbps
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 8 x 100/1000/2500 Mbps RJ45 Ports
2 x 10G SFP+ Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): Standard: 802.3at/af compliant
PoE+ Ports: 8 Ports
PoE Power Budget: 240 W - Switching Capacity: 80 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
- Dimensions: 440 x 180 x 44 mm
- Mac Address Table: 16 K
- Packet Forwarding Rate: 59.52 Mpps
- Jumbo Frame: 9 KB
- Additional Features: Support Omada Hardware/Software/Cloud-Based Controller
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
ZTP (Zero-Touch Provisioning) - Quality of Service: 8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
Bandwidth Control
Smoother Performance
Action for Flows - Layer Features: L2 and L2+:
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
MirroringL3:
16 IPv4/IPv6 Interfaces
Static Routing
Static ARP
Proxy ARP
Gratuitous ARP
DHCP Server
DHCP Relay
DHCP L2 Relay - VLAN: “VLAN Group
802.1Q Tagged VLAN
MAC VLAN: 7 Entries
Protocol VLAN: Template 16, VLAN 16
Private VLAN
GVRP
VLAN VPN (QinQ)
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management – HTTPS with SSLv3/TLS 1.2
Secure CLI management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Web-based GUI
CLI through the console port, telnet
SNMP v1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: Operating Temperature: 0–50 °C
Storage Temperature: -40–70 °C
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: TL-SG3210XHP-M2 Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 3.3000 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
3 in stock
TP-LINK (TL-SG3210XHP-M2) JetStream 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ L2+ Managed Switch with 8-Port PoE+,Rackmountable
£347.85 Add to basketQuick View -
£333.93
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 24
- Max RJ45 Transfer Rate: 2.5 Gbps
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 24 x 2.5 Gbps RJ45 Ports
4 x 10G SFP+ Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): 8-Port PoE++ and 16-Port PoE+ 2.5 Gbps ports with up to 500W power budget
- Switching Capacity: 200 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
- Dimensions: (WxDxH) 440 x 180 x 44 mm
- Mac Address Table: 32 K
- Packet Forwarding Rate: 148.80 Mpps
- Jumbo Frame: 9 KB
- Additional Features: Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule - Quality of Service: 8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
Bandwidth Control
Smoother Performance
Action for Flows - Layer Features: L2 and L2+:
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
MirroringL2 Multicast:
IGMP Snooping
IGMP Authentication
MLD Snooping
MVR
Multicast Filtering: 256 profiles and 16 entries per profileL3:
32 IPv4/IPv6 Interfaces
Static Routing
Static ARP
Proxy ARP
Gratuitous ARP
DHCP Server
DHCP Relay
DHCP L2 Relay - VLAN: “VLAN Group
802.1Q Tagged VLAN
MAC VLAN: 256 Entries
Protocol VLAN: Protocol Template 16, Protocol VLAN 16
GVRP
VLAN VPN (QinQ)
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure Command Line Interface (CLI) management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Require Omada Controllers:
Omada App
Centralized Management
Cloud Access
Zero-Touch ProvisioningManagement Features:
Web-based GUI
Command Line Interface (CLI) through the console port, telnet
SNMP v1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: Operating Temperature: 0–40°C (32–104°F)
Storage Temperature: -40–70°C (-40–158°F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: TL-SG3428X-M2 Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 3.0500 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
Out of stock
TP-LINK (TL-SG3428X-M2) JetStream 24-Port 2.5GBASE-T L2+ Managed Switch with 4 10GE SFP+ Slots, PoE++, Rackmountable
£333.93 Read moreQuick View -
£333.93
Description
Specification
- Rackmountable: No
- Managed: Smart
- Number of Ports: 8
- Max RJ45 Transfer Rate: 2.5 Gbps
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 8 x 100/1000/2500 Mbps RJ45 PoE+ Ports
2 x 10G SFP+ Slots - PoE Ports (RJ45): Standard: 802.3at/af compliant
PoE+ Ports: 8 Ports
PoE Power Budget: 160 W - Switching Capacity: 80 Gbps
- Power Supply: 53.5VDC/3.37A Power Adapter
- Dimensions: 226 x 131 x 35 mm
- Mac Address Table: 16 K
- Packet Forwarding Rate: 59.52 Mpps
- Jumbo Frame: 9KB
- Additional Features: Fanless design for quiet operation
Desktop/Wall-Mounting
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule - Quality of Service: 802.1p CoS/DSCP priority
8 priority queues
Priority Schedule Mode
Queue Weight Config
Bandwidth Control
Smoother Performance
Storm Control - Layer Features: L2 and L2+:
32 IP Interfaces: Support IPv4/IPv6 Interface
Static Routing: 32 IPv4/IPv6 Static Routes
DHCP Server
DHCP Relay
DHCP L2 Relay
Static ARP
Proxy ARP
Gratuitous ARP
Link Aggregation
Spanning Tree Protocol
Loopback Detection
802.3x Flow Control
Mirroring
Device Link Detect Protocol (DLDP)
802.1ab LLDP/ LLDP-MED - .: “L2 Multicast:
511 IPv4, IPv6 shared multicast groups
IGMP Snooping
Multicast VLAN Registration (MVR)
Multicast Filtering
Limited IP Multicast (256 profiles and 16 entries per profile)” - VLAN: VLAN Group – Max 4K VLAN Groups
802.1Q Tagged VLAN
MAC VLAN: 12 Entries
Protocol VLAN
GVRP
Voice VLAN - Access Control: Support up to 230 entries
Time-based ACL
MAC ACL
IP ACL
IPv6 ACL
Combined ACL
Rule Operation: Permit/Deny
Policy Action
ACL Rules Binding - Security: IP-MAC-Port Binding
AAA
802.1X
IP/IPv6-MAC Binding
IP Source Guard
IPv6 Source Guard
DoS Defend
DHCP Filter
Static/Dynamic/Permanent Port Security
Broadcast/Multicast/Unicast Storm Control
Port Isolation
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure Command Line Interface (CLI) management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Require Omada Controllers:
Omada App
Centralized Management
Cloud Access
Zero-Touch ProvisioningManagement Features:
Web-based GUI
CLI through telnet
SNMPv1/v2c/v3
SNMP Trap/Inform
RMON (1,2,3,9 groups)
SDM Template
DHCP/BOOTP Client
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
SNTP
System Log” - Environment: Operating Temperature: 0–40°C (32–104°F)
Storage Temperature: -40–70°C (-40–158°F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: SG2210XHP-M2 Switch
Power Adapter
Quick Installation Guide
Rubber Feet - Package Type: Retail
- Package Weight: 2.2600 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
6 in stock
TP-LINK (SG2210XMP-M2) Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ Smart Switch with 8-Port PoE+
£333.93 Add to basketQuick View -
£313.07
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 48
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 48 x 10/100/1000Mbps RJ45 (Auto Negotiation/MDI/MDIX)
4 x 1000Mbps SFP Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): –
- Bandwidth: 104Gbps
- Standards and Protocols: “IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z,
IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s,
IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p” - Power Supply: “100~240VAC, 50/60Hz
Max Power Consumption: 33.52W (220V/50Hz)” - Dimensions: 440 x 220 x 44 mm
- Mac Address Table: 16k
- Packet Forwarding Rate: 77.4Mpps
- Jumbo Frame: 9216 Bytes
- Additional Features: See Overview
- Quality of Service: L2/L3/L4 QoS and IGMP
- Layer Features: “L2 and L2+:
Static Routing. DHCP Relay
IGMP Snooping V1/V2/V3
802.3ad LACP (Up to 14 agg. groups, 8 ports per group)
Spanning Tree STP/RSTP/MSTP
BPDU Filtering/Guard
TC/Root Protect
Loopback detection
802.3x Flow Control
L2PT” - VLAN: Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs)
Port/ MAC/Protocol-based/Private VLAN
GARP/GVRP - Access Control: “L2~L4 package filtering based on source and destination MAC address,
IP address, TCP/UDP ports, 802.1p, DSCP, protocol and VLAN ID
Time Range Based” - Security: IP-MAC-Port-VID Binding
AAA
802.1x and Radius Authentication
DoS Defend
Dynamic ARP inspection (DAI)
SSH v1/v2
SSL v3/TLSv1
Port Security
Broadcast/Multicast/Unknown-unicast Storm Control - Management: “Web-based GUI and CLI management
SNMP v1/v2c/v3 (public & TP-LINK private MIBs)
RMON (1, 2, 3, 9 groups)
sFlow*
PPPoE Circuit ID
DHCP Relay
DHCP Server
DHCP/BOOTP Client, DHCP Snooping, DHCP Option82
Dual Image
CPU Monitoring
Port Mirroring
Time Setting: SNTP
Integrated NDP/NTDP feature
Firmware Upgrade: TFTP & Web
System Diagnose: VCT
SYSLOG & Public MIBS
Password Recovery” - Environment: “Operating Temperature: 0C~40C (32F~104F);
Storage Temperature: -40C~70C (-40F~158F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing” - Package Contents: JetStream 48-Port Switch – T2600G-52TS
Power Cord
Installation Guide
Resource CD
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 3.7000 kg
- Warranty: Limited Lifetime
- #Hide#POE: No
15 in stock
TP-LINK (TL-SG3452) JetStream 48-Port Gigabit L2 Managed Network Switch with 4 SFP Slots, L2/L3/L4 QoS, Fanless, Rackmountable
£313.07 Add to basketQuick View -
£306.11
Description
Specification
- Rackmountable: Yes
- Managed: No
- Number of Ports: 8
- Max RJ45 Transfer Rate: 10 Gbps
- Interface(s): “8 x 100Mbps/1Gbps/2.5Gbps/5Gbps/10Gbps Ports
Auto-Negotiation, Auto-MDI/MDIX” - PoE Ports (RJ45): –
- Standards and Protocols: “IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, 802.3an, 802.3bz”
- Switching Capacity: 160 Gbps
- LED: “System Power: 1
Link/Act Indicators: 8, 1 indicator per port built into each RJ-45 port” - Power Supply: “100-240 VAC, 50/60 Hz, 0.8A
Max Power Consumption: 31.2 W” - Dimensions: 294 x 180 x 44 mm
- Transfer Method: Store and Forward
- Mac Address Table: 32 K
- Packet Forwarding Rate: 2 Mb
- Jumbo Frame: 10 KB
- Additional Features: 802.3X Flow Control
- Quality of Service: 802.1p/DSCP QoS
- Management: –
- Environment: Operating Temperature: 0–40 °C (32–104 °F)
Storage Temperature: -40–70 °C (-40–158 °F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: 8-Port 10G Multi-Gigabit Switch
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 2.0860 kg
- Warranty: Limited Lifetime
- #Hide#POE: No
6 in stock
TP-LINK (TL-SX1008) 8-Port Unmanaged 10G Multi-Gigabit Desktop/Rackmount Switch, 8x 100/1G/2.5G/5G/10G, Low-Noise Fan, Steel Case
£306.11 Add to basketQuick View -
£278.27
Description
Specification
- Rackmountable: Yes
- Managed: Smart
- Number of Ports: 28
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 24 x 10/100/1000 Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
4 x Gigabit SFP Slots - PoE Ports (RJ45): Standard: 802.3at/af compliant
PoE+ Ports: 24 Ports
Power Supply: 250 W - Bandwidth: 56 Gbps
- Standards and Protocols: “IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x”
- Power Supply: PoE
Max Consumption:
32.1 W (110 V/ 60 Hz with no PD connected)
308.6 W (110 V/ 60 Hz with 250 W PD connected) - Dimensions: 440 x 220 x 44 mm
- Mac Address Table: 8K
- Packet Forwarding Rate: 41.7 Mpps
- Jumbo Frame: 9KB
- Additional Features: See Overview
- Quality of Service: “Support 802.1p CoS/DSCP priority
Support 8 priority queues
Queue scheduling: SP, WRR, SP+WRR
Port/Flow- based Rate Limiting
IPv6 QoS
Voice VLAN” - Layer Features: “Static Routing
DHCP Relay
DHCP Server
IGMP Snooping V1/V2/V3
Spanning Tree STP/RSTP/MSTP
BPDU Filtering/Guard
TC/Root Protect
Loopback detection
802.3x Flow Control
LLDP, LLDP-MED
802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group)” - VLAN: Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs)
MAC/Protocol-based VLAN - Access Control: L2–L4 package filtering
MAC ACL
IP ACL
Combined ACL
IPv6 ACL - Security: AAA
Port Security
DHCP Snooping
IP-MAC-Port Binding
IPv6-MAC-Port Binding
ARP Inspection
802.1x and Radius Authentication
SSH v1/v2
SSL v3/TLSv1.2
Broadcast/Multicast/Unknown-unicast Storm Control
Dos Defend - Management: “Omada App
Omada Cloud-Based Controller
Centralized Management
Web-based GUI and CLI management
SNMP v1/v2c/v3 (public MIBs and TP-Link private MIBs)
RMON (1, 2, 3, 9 groups)
CPU Monitoring
Port Mirroring
Firmware Upgrade: TFTP & Web
System Diagnose: VCT
SYSLOG & Public MIBS
Dual Image
EEE” - Environment: “Operating Temperature: 0–50C (32–122F);
Storage Temperature: -40–70C (-40–158F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing” - Package Contents: TL-SG2428P
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 4.1000 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
30 in stock
TP-LINK (TL-SG2428P) JetStream 28-Port Gigabit Smart Switch with 24-Port PoE+, 4 GB SFP Slots, Rackmountable
£278.27 Add to basketQuick View -
£250.45
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 24
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 24 x 10/100/1000 Mbps RJ45 Ports
4 x 10G SFP+ Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): –
- Switching Capacity: 128 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
- Dimensions: 440 x 180 x 44 mm
- Mac Address Table: 16 K
- Packet Forwarding Rate: Forwarding
- Jumbo Frame: 95.23 Mpps
- Additional Features: Support Omada Hardware/Software/Cloud-Based Controller
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
ZTP (Zero-Touch Provisioning) - Quality of Service: 8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
Bandwidth Control
Smoother Performance
Action for Flows - Layer Features: L2 and L2+:
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
MirroringL3:
16 IPv4/IPv6 Interfaces
Static Routing
Static ARP
Proxy ARP
Gratuitous ARP
DHCP Server
DHCP Relay
DHCP L2 Relay - VLAN: “VLAN Group
802.1Q Tagged VLAN
MAC VLAN: 7 Entries
Protocol VLAN: Template 16, VLAN 16
Private VLAN
GVRP
VLAN VPN (QinQ)
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management – HTTPS with SSLv3/TLS 1.2
Secure CLI management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Web-based GUI
CLI through the console port, telnet
SNMP v1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: “Operating Temperature: 0–45C (32–113F);
Storage Temperature: -40–70C (-40–158F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing” - Package Contents: TL-SG3428X Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 2.6690 kg
- Warranty: Limited Lifetime
- #Hide#POE: No
6 in stock
TP-LINK (TL-SG3428X) JetStream 24-Port Gigabit L2+ Managed Switch with 4 10GE SFP+ Slots, L2+/L3, Fanless, Rackmountable
£250.45 Add to basketQuick View -
£235.15
Description
Specification
- Rackmountable: Yes
- Managed: No
- Number of Ports: 5
- Max RJ45 Transfer Rate: 10 Gbps
- Interface(s): “5 x 100Mbps/1Gbps/2.5Gbps/5Gbps/10Gbps Ports
Auto-Negotiation, Auto-MDI/MDIX” - PoE Ports (RJ45): –
- Standards and Protocols: “IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1p, 802.3an, 802.3bz”
- Switching Capacity: 100 Gbps
- LED: “System Power: 1
Link/Act Indicators: 5, 1 indicator per port built into each RJ-45 port” - Power Supply: External Power Adapter (Output: 12 VDC / 2.0 A)
Max Power Consumption: 21.4 W - Dimensions: 226 x 131 x 35 mm
- Transfer Method: Store and Forward
- Mac Address Table: 32 K
- Packet Forwarding Rate: 2 Mb
- Jumbo Frame: 10 KB
- Additional Features: 802.3X Flow Control
- Quality of Service: 802.1p/DSCP QoS
- Management: –
- Environment: Operating Temperature: 0–40 °C (32–104 °F)
Storage Temperature: -40–70 °C (-40–158 °F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: 5-Port 10G Multi-Gigabit Switch
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 1.6100 kg
- Warranty: Limited Lifetime
- #Hide#POE: No
Out of stock
TP-LINK (TL-SX105) 5-Port Unmanaged 10G Multi-Gigabit Desktop/Rackmount Switch, 5x 100/1G/2.5G/5G/10G, Fanless, Steel Case
£235.15 Read moreQuick View -
£219.09
Description
Specification
- Rackmountable: Yes
- Managed: No
- Number of Ports: 48
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- Interface(s): 48 x 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX - Power Supply: “100-240VAC, 50/60Hz”
- Dimensions: 17.3 x 10.2 x 1.7 in. (440 x 260 x 44 mm)
- Transfer Method: Store and Forward
- Mac Address Table: 8K
- Additional Features: “802.3X Flow Control, Back Pressure
Auto-Uplink Every Port” - Environment: “Operating Temperature: 0C~40C (32F~104F);
Storage Temperature: -40C~70C (-40F~158F);
Operating Humidity: 10%~90% non-condensing;
Storage Humidity: 5%~90% non-condensing” - Package Contents: 48-Port Gigabit Rackmount Switch
Power Cord
Installation Guide
Rackmount Kits
Rubber Feet - Package Type: Retail
- Package Weight: 3.7900 kg
- Warranty: Limited Lifetime
- #Hide#POE: No
22 in stock
TP-LINK (TL-SG1048) 48-Port Gigabit Unmanaged Rackmount Switch, Steel Case
£219.09 Add to basketQuick View -
£215.67
Description
Specification
- Rackmountable: Yes
- Managed: Smart
- Number of Ports: 18
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 16 x 10/100/1000 Mbps RJ45 (Auto Negotiation/Auto MDI/MDIX)
2 x Gigabit SFP - PoE Ports (RJ45): PoE+ Ports: 16 Ports
PoE Power Budget: 150 W - Standards and Protocols: “IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x”
- Switching Capacity: 36 Gbps
- Power Supply: “100-240V AC, 50/60Hz”
- Mac Address Table: 8K
- Packet Forwarding Rate: 26.78 Mpps
- Jumbo Frame: 9 KB
- Additional Features: Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule - Quality of Service: 802.1p CoS/DSCP priority
8 priority queues
Priority Schedule Mode
Queue Weight Config
Bandwidth Control
Smoother Performance
Storm Control - Layer Features: L2 and L2+:
16 IP Interfaces
Static Routing
DHCP Server
DHCP Relay
DHCP L2 Relay
Static ARP
Proxy ARP
Gratuitous ARP
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
Mirroring
Device Link Detect Protocol (DLDP)
802.1ab LLDP/ LLDP-MED - VLAN: VLAN Group
802.1Q tag VLAN
MAC VLAN: 12 Entries
Protocol VLAN
GVRP
Voice VLAN - Access Control: Support up to 230 entries
Time-Range
Time-based ACL
MAC ACL
IP ACL
IPv6 ACL
Combined ACL
Rule Operation
Policy Action
ACL Rules Binding
Actions for flows - Security: AAA
802.1X
IP/IPv6-MAC Binding
IP Source Guard
IPv6 Source Guard
DoS Defend
Static/Dynamic/Permanent Port Security
Broadcast/Multicast/Unicast Storm Control
Port Isolation
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure Command Line Interface management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Require Omada Controllers:
Omada App
Centralized Management
Cloud Access
Zero-Touch ProvisioningManagement Features:
Management Features
Web-based GUI
Command Line Interface (CLI) through telnet
SNMPv1/v2c/v3
SNMP Trap/Inform
RMON (1,2,3,9 groups)
SDM Template
DHCP/BOOTP Client
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
SNTP
System Log” - Environment: Operating Temperature: 0–50°C (32–122°F)
Storage Temperature: -40–70°C (-40–158°F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: TL-SG2218P
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 3.2000 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
Out of stock
TP-LINK (TL-SG2218P) JetStream 18-Port Gigabit Smart Switch w/ 16-Port PoE+, 2x SFP, IPv6, Centralised Management
£215.67 Read moreQuick View -
£208.71
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 8
- #Hide#Max SFP Transfer Rate: 10G SFP
- Interface(s): 8 x 10GE SFP+ Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): –
- Switching Capacity: 160 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
Max Power Consumption: 15.46 W (220 V / 50 Hz) - Dimensions: (W x D x H) 440 x 180 x 44 mm
- Mac Address Table: 32 K
- Packet Forwarding Rate: 119.04 Mpps
- Jumbo Frame: 9 KB
- Additional Features: “Support Omada Hardware, Software & Cloud-Based Controller
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
ZTP (Zero-Touch Provisioning)” - Quality of Service: Advanced Quality of Service
- Layer Features: L2 and L2+ Features
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
MirroringL2 Multicast
IGMP Snooping
IGMP Authentication
MLD Snooping
MVR
Multicast Filtering: 256 profiles & 16 entries per profileLL3 Features
16 IPv4/IPv6 Interfaces
Static Routing
Static ARP
Proxy ARP
Gratuitous ARP
DHCP Server
DHCP Relay
DHCP L2 Relay - VLAN: “VLAN Group
802.1Q Tagged VLAN
MAC VLAN: 7 Entries
Protocol VLAN: Protocol Template 16, Protocol VLAN 16
Private VLAN
GVRP
VLAN VPN (QinQ)
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management – HTTPS with SSLv3/TLS 1.2
Secure CLI management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Web-based GUI
CLI through the console port, telnet
SNMP v1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: Operating Temperature: 0–45 °C (32–113 °F)
Storage Temperature: -40–70 °C (-40–158 °F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 2.4000 kg
- Warranty: Limited Lifetime
- #Hide#POE: No
5 in stock
TP-LINK (TL-SX3008F) JetStream 8-Port 10GE SFP+ L2+ Managed Switch, Centralized Management, Fanless, Rackmountable
£208.71 Add to basketQuick View -
£194.80
Description
Specification
- Rackmountable: Yes
- Managed: Smart
- Number of Ports: 28
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 26 x 10/100/1000 Mbps RJ45 Ports
2 x Gigabit SFP Ports - PoE Ports (RJ45): Standard: 802.3at/802.3af compliant
PoE+ Ports: 24 Ports
Power Supply: 250 W - Standards and Protocols: “IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
IEEE 802.3af, IEEE 802.3at, IEEE 802.1q, IEEE 802.1p” - Switching Capacity: 56 Gbps
- Power Supply: “100-240V AC, 50/60 Hz
Max Consumption:
27 W (220/50Hz. no PD connected)
304.7 W (220/50Hz. with 250 W PD connected)” - Dimensions: 440 x 220 x 44 mm
- Mac Address Table: 8K
- Packet Forwarding Rate: 41.7 Mbps
- Jumbo Frame: 9 KB
- Additional Features: See Overview
- Quality of Service: Support Port-based 802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control - Layer Features: L2 Features:
IGMP Snooping V1/V2/V3
Static Link Aggregation
Port Mirroring
Cable Diagnostics
Loop Prevention
PoE Auto Recovery - VLAN: Support up to 32 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN - Security: Physical security lock
- Management: Web-Based GUI
Easy Smart Configuration Utility - Environment: Operating Temperature: 0°C~50°C (32°F~122°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5%~90% non-condensing - Package Contents: TL-SG1428PE
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 4.0000 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
Out of stock
TP-LINK (TL-SG1428PE) 28-Port Gigabit PoE+ Easy Smart Switch, 24-Port PoE+, 2 SFP Ports, Rackmountable
£194.80 Read moreQuick View -
£187.84
Description
Specification
- Rackmountable: Yes
- Managed: Smart
- Number of Ports: 28
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 24 x 10/100Mbps RJ45 Ports
(Auto Negotiation/Auto MDI/MDIX)
4 x 10/100/1000Mbps RJ45 Ports
(Auto Negotiation/Auto MDI/MDIX)
2 x Combo Gigabit SFP Slots - PoE Ports (RJ45): Standard: 802.3at/af compliant
PoE+ Ports: 24 Ports
Power Supply: 250W - Standards and Protocols: “IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q,
IEEE 802.1p” - Switching Capacity: 12.8 Gbps
- Power Supply: “100~240VAC, 50/60Hz”
- Dimensions: (W x D x H) 440 x 180 x 44 mm
- Mac Address Table: 8k
- Packet Forwarding Rate: 9.5Mpps
- Jumbo Frame: 9216 Bytes
- Quality of Service: 802.1p CoS/DSCP priority
8 priority queues
Priority Schedule Mode
Bandwidth Control
Smoother Performance
Storm Control - Layer Features: “Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
Mirroring
Device Link Detect Protocol (DLDP)L2 Multicast
512 IPv4, IPv6 shared multicast groups
IGMP Snooping
MLD Snooping
Multicast VLAN Registration
Multicast Filtering” - VLAN: VLAN Group
802.1Q tag VLAN
MAC VLAN
Protocol VLAN
GVRP
Voice VLAN - Access Control: P/Port/MAC
- Security: AAA
802.1X
EAP-TLS/EAP-TTLS/EAP-PEAP
IP/IPv6-MAC Binding
IP Source Guard
IPv6 Source Guard
DoS Defend
Static/Dynamic/Permanent Port Security
Broadcast/Multicast/Unicast Storm Control
Port Isolation
Secure web management (HTTPS with SSLv3/TLS1.0)
Secure CLI management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Web-based GUI
CLI through telnet
SNMPv1/v2c/v3
SNMP Trap/Inform
RMON (1,2,3,9 groups)
SDM Template
DHCP/BOOTP Client
CPU Monitoring
Cable Diagnostics
EEE
System Log
802.1ab LLDP/ LLDP-MED” - Package Contents: T1500-28PCT
Power Cord
Installation Guide
Resource CD
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 3.1000 kg
- Warranty: Limited lifetime
- #Hide#POE: Yes
8 in stock
TP-LINK (T1500-28PCT) 24-Port Smart PoE Switch, 24 x 10/100Mbps PoE+ 4-Port Gigabit, 2 Combo GB SFP Slots, Rackmountable
£187.84 Add to basketQuick View -
£180.88
Description
Specification
- Rackmountable: Yes
- Managed: Smart
- Number of Ports: 16
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 16 x 10/100/1000 Mbps RJ45 Ports
(Auto Negotiation/Auto MDI/MDIX)
2 x Gigabit SFP Ports - PoE Ports (RJ45): Standard: 802.3at/802.3af compliant
PoE+ Ports: 16 Ports
Power Supply: 192W - Standards and Protocols: “IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
IEEE 802.3af, IEEE 802.3at, IEEE 802.1q, IEEE 802.1p” - Switching Capacity: 36Gbps
- Power Supply: “100-240V AC, 50/60 Hz”
- Dimensions: 440 x 180 x 44 mm
- Mac Address Table: 8K
- Port Forwarding: Yes
- Packet Forwarding Rate: 23.8 Mbps
- Jumbo Frame: 9 KB
- Additional Features: See Overview
- Quality of Service: Support Port-based 802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control - VLAN: Support up to 32 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN - Management: Web-based GUI
Easy Smart Configuration Utility - Environment: Operating Temperature: 0°C~50°C (32°F~122°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5%~90% non-condensing - Package Contents: TL-SG1218MPE
Power Cord
Installation Guide
Resource CD
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 3.0500 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
Out of stock
TP-LINK (TL-SG1218MPE) 16-Port Gigabit PoE+ Easy Smart Switch, 2 SFP Ports, Rackmountable
£180.88 Read moreQuick View -
£180.88
Description
Specification
- Rackmountable: Yes
- Managed: Smart
- Number of Ports: 10
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: 2.5G SFP
- Interface(s): “8 x 10/100/1000 Mbps RJ45 Ports, all supporting PoE+ (Auto-Negotiation/Auto MDI/MDIX)
2 x 100/1000 Mbps SFP Slots” - PoE Ports (RJ45): Standard: 802.3at/af compliant
PoE+ Ports: 8 Ports
Power Supply: 150 W - Standards and Protocols: “IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p”
- Switching Capacity: 20 Gbps
- Power Supply: PoE
Max Consumption:
12.2 W (110 V / 60 Hz with no PD connected)
173.9 W (110 V / 60 Hz with 150 W PD connected) - Dimensions: 294 x 180 x 44 mm
- Mac Address Table: 8K
- Packet Forwarding Rate: 14.9 Mpps
- Jumbo Frame: 9 KB
- Additional Features: See Overview
- Quality of Service: 802.1p CoS/ DSCP priority
8 priority queues
Priority Schedule Mode
Queue Weight Config
Bandwidth Control
Smoother Performance
Actions for flows
Storm Control - Layer Features: DHCP Relay
DHCP L2 Relay
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
Mirroring
Device Link Detect Protocol (DLDP)
802.1ab LLDP/ LLDP-MED - VLAN: VLAN Group
802.1Q tag VLAN
MAC VLAN
Protocol VLAN
GVRP
Voice VLAN - Access Control: Support up to 230 entries
Time-Range
Time-based ACL
MAC ACL
IP ACL
IPv6 ACL
Combined ACL
Rule Operation
Policy Action
ACL Rules Binding - Security: AAA
802.1X
IP/IPv6-MAC Binding
IP Source Gurad
IPv6 Source Gurad
DoS Defend
Static/Dynamic/Permanent Port Security
Broadcast/Multicast/Unicast Storm Control
Port Isolation
Secure web management through HTTPS with SSLv3/TLS1.2
Secure Command Line Interface management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Omada App
Centralized Management
Web-based GUI and CLI management
SNMPv1/v2c/v3
SNMP Trap/Inform
RMON (1,2,3,9 groups)
SDM Template
DHCP/BOOTP Client
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
System Log
802.1ab LLDP/ LLDP-MED” - Environment: “Operating Temperature: 0C~40C (32F~104F);
Storage Temperature: -40C~70C (-40F~158F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing” - Package Contents: TL-SG2210MP
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 2.1600 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
6 in stock
TP-LINK (TL-SG2210MP) JetStream 10-Port Gigabit Smart Switch with 8-Port PoE+, 2 GB SFP Slots, Rackmountable
£180.88 Add to basketQuick View -
£175.31
Description
Specification
- Rackmountable: Yes
- Managed: No
- Number of Ports: 24
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 24 x PoE+ 10/100 Mbps RJ45 Ports
2 x 10/100/1000 Mbps RJ45 Ports
2 x Combo Gigabit SFP Slots - PoE Ports (RJ45): Standard: 802.3at/802.3af compliant
PoE Ports: Port 1 – Port 24
PoE Power Budget: 250 W - Bandwidth: 8.8 Gbps
- Power Supply: “100-240 VAC, 50/60 Hz”
- Dimensions: 440 x 180 x 44 mm (W x D x H)
- Mac Address Table: 8 K
- Additional Features: Compatible With IEEE 802.3at/af Compliant PDs
Extend Mode (Up to 250m PoE power supply and data transmission)
Priority Mode
Isolation Mode
PD Detection
Intelligent Power Supply
Mac Address Auto-Learning and Auto-Aging
IEEE802.3x Flow Control - Security: Physical Security Lock
- Management: –
- Environment: Operating Temperature: 0–50 °C (32–122 °F)
Storage Temperature: -40–70 °C (-40–158 °F)
Operating Humidity: 10–90% non-condensing
Storage Humidity: 5–90% non-condensing - Package Contents: TL-SL1226P
Power Cable
Installation Guide
Two mounting brackets and the fittings - Package Type: Retail
- Package Weight: 2.9600 kg
- Warranty: Lifetime Warranty
- #Hide#POE: Yes
10 in stock
TP-LINK (TL-SL1226P) 24-Port 10/100Mbps + 2-Port GB Unmanaged PoE+ Switch, 2 combo GB SFP Slots, 24-Port PoE, Rackmountable
£175.31 Add to basketQuick View -
£164.18
Description
Specification
- Rackmountable: Yes
- Managed: No
- Number of Ports: 18
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 16 x PoE+ gigabit RJ45 ports
2 x gigabit non-PoE RJ45 ports
2 x combo gigabit SFP slots - PoE Ports (RJ45): Standard: 802.3at/802.3af compliant
PoE Ports: Ports 1–16
PoE Power Budget: 250 W - Standards and Protocols: “IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.1q, IEEE 802.1p”
- Switching Capacity: 36 Gbps
- Power Supply: “100–240 VAC, 50/60 Hz
Max Consumption:
21.4 W (220/50 Hz. no PD connected)
286.64 W (220/50 Hz. with 250 W PD connected)” - Dimensions: 440 x 180 x 44 mm
- Mac Address Table: 8K
- Packet Forwarding Rate: 26.78 Mbps
- Jumbo Frame: 10 KB
- Additional Features: See Overview
- Quality of Service: 802.1p/DHCP QoS
- Security: Physical security lock
- Management: –
- Environment: Operating Temperature: 0–50 °C (32–122 °F)
Storage Temperature: -40–70 °C (-40–158 °F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: TL-SG1218MP
Installation Guide
Power Cord
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 3.0700 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
Out of stock
TP-LINK (TL-SG1218MP) 18-Port Gigabit Unmanaged PoE+ Rackmount Switch, 16-Port PoE+, 2 SFP Ports
£164.18 Read moreQuick View -
TP-LINK (TL-SG2016P) JetStream 16-Port Gigabit Smart Switch with 8-Port PoE+, Centralized Management£160.02
Description
Specification
- Rackmountable: No
- Managed: Smart
- Number of Ports: 16
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- Interface(s): 16 x 10/100/1000 Mbps RJ45 Ports
Auto-Negotiation/Auto MDI/MDIX - PoE Ports (RJ45): Ports 1–8 Support 802.3at/af PoE+
Power Supply: 120 W - Bandwidth: 16 Gbps
- Standards and Protocols: “IEEE 802.3i, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x”
- Power Supply: External Power Adapter (Output: 53.5 VDC/ 1.31 A)
- Dimensions: 286 x 111.7 x 25.4 mm
- Mac Address Table: 8k
- Jumbo Frame: 9 KB
- Additional Features: See Overview
- Quality of Service: 802.1p CoS/DSCP priority
8 priority queues
Priority Schedule Mode
Queue Weight Config
Bandwidth Control
Smoother Performance
Storm Control - Layer Features: “L2 and L2+:
DHCP Relay
DHCP L2 Relay
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
Mirroring
Device Link Detect Protocol (DLDP)
802.1ab LLDP/ LLDP-MEDL2 Multicast:
511 IPv4, IPv6 shared multicast groups
IGMP Snooping
Multicast VLAN Registration (MVR)
Multicast Filtering
MLD Snooping
Limited IP Multicast (256 profiles and 16 entries per profile)” - VLAN: VLAN Group – Max. 4K VLAN Groups
802.1Q tag VLAN
MAC VLAN: 12 Entries
Protocol VLAN
GVRP
Voice VLAN - Access Control: Support up to 230 entries
Time-Range
Time-based ACL
MAC ACL
IP ACL
IPv6 ACL
Combined ACL
Rule Operation
Policy Action
ACL Rules Binding
Actions for flows - Security: AAA
802.1X
IP/IPv6-MAC Binding
IP Source Guard
IPv6 Source Guard
DoS Defend
Static/Dynamic/Permanent Port Security
Broadcast/Multicast/Unicast Storm Control
Port Isolation
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure CLI management with SSHv1/SSHv2
IP/Port/MAC-based access control - Management: “Require Omada Controllers:
Omada App
Centralized Management
Cloud Access
Zero-Touch ProvisioningManagement Features:
Web-based GUI
Command Line Interface (CLI) through telnet
SNMPv1/v2c/v3
SNMP Trap/Inform
RMON (1,2,3,9 groups)
SDM Template
DHCP/BOOTP Client
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
SNTP
System Log” - Environment: Operating Temperature: 0–40°C (32–104°F)
Storage Temperature: -40–70°C (-40–158°F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: TL-SG2016P
Power Adapter
Installation Guide
Rubber Feet - Package Type: Retail
- Package Weight: 2.3000 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
10 in stock
TP-LINK (TL-SG2016P) JetStream 16-Port Gigabit Smart Switch with 8-Port PoE+, Centralized Management
£160.02 Add to basketQuick View -
£153.05
Description
Specification
- Rackmountable: Yes
- Managed: Yes
- Number of Ports: 24
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 24 x 10/100/1000 Mbps RJ45 Ports
4 x Gigabit SFP Slots
1 x RJ45 Console Port
1 x Micro-USB Console Port - PoE Ports (RJ45): –
- Switching Capacity: 56 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
Max Power Consumption: 19.22 W (110 V/60 Hz) - Dimensions: 440 x 180 x 44 mm
- Mac Address Table: 8K
- Packet Forwarding Rate: 41.66 Mpps
- Jumbo Frame: 9 KB
- Additional Features: Support Omada Hardware/Software/Cloud-Based Controller
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
ZTP (Zero-Touch Provisioning) - Quality of Service: 8 priority queues
802.1p CoS/DSCP priority
Queue scheduling
Bandwidth Control
Smoother Performance
Action for Flows - Layer Features: L2 and L2+:
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
MirroringL3:
16 IPv4/IPv6 Interfaces
Static Routing
Static ARP
316 ARP Entries
Proxy ARP
Gratuitous ARP
DHCP Server
DHCP Relay
DHCP L2 Relay - VLAN: “VLAN Group
802.1q Tagged VLAN
MAC VLAN: 12 Entries
Protocol VLAN: Protocol Template 16, Protocol VLAN 16
GVRP
VLAN VPN (QinQ)
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
IP/Port/MAC based access control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management – HTTPS with SSLv3/TLS 1.2
Secure CLI management with SSHv1/SSHv2 - Management: “Web-based GUI
Command Line Interface (CLI) through console port, telnet
SNMPv1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: Operating Temperature: 0–45C (32–113F)
Storage Temperature: -40–70C (-40–158F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: TL-SG3428 Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 2.6840 kg
- Warranty: Limited Lifetime
- #Hide#POE: No
Out of stock
TP-LINK (TL-SG3428) JetStream 24-Port Gigabit L2 Managed Switch with 4 SFP Slots, Console Port, Fanless, Rackmountable
£153.05 Read moreQuick View -
£141.93
Description
Specification
- Rackmountable: No
- Managed: No
- Number of Ports: 5
- Max RJ45 Transfer Rate: 2.5 Gbps
- Interface(s): 5 x 10 Mbps/100 Mbps/1 Gbps/2.5 Gbps RJ45 ports
AUTO Negotiation
AUTO MDI/MDIX - PoE Ports (RJ45): Standard: 802.3 af/at/bt type3 compliant
PoE++ Ports: Ports 1–4
Power Supply: 123 W - Switching Capacity: 25 Gbps
- Power Supply: External Power Adapter (Output: 53.5 VDC / 2.43 A)
- Dimensions: (WxDxH) 209 x 126 x 26 mm
- Transfer Method: Store-And-Forward
- Mac Address Table: 4K
- Packet Forwarding Rate: 18.6 Mpps
- Additional Features: Compatible w/ IEEE 802.3af/at/bt type3 Compliant PDs
Mac Address Auto-Learning And Auto-Aging
IEEE 802.3x Flow Control
802.1p/DSCP QoS
IGMP Snooping
PoE Auto Recovery (Ports 1-4) - Environment: Operating Temperature: 0–40°C (32–104°F)
Storage Temperature: -40–70°C (-40–158°F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: TL-SG105PP-M2
Power Adapter
Installation Guide
Rubber Feet - Package Type: Retail
- Package Weight: 1.7000 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
12 in stock
TP-LINK (TL-SG105PP-M2) 5-Port 2.5G Desktop Switch with 4-Port PoE++
£141.93 Add to basketQuick View -
£134.96
Description
Specification
- Rackmountable: No
- Managed: No
- Number of Ports: 10
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 9 x 10/100/1000Mbps RJ45 Ports
1 x 1000Mbps Combo SFP/RJ45 Port
AUTO Negotiation
AUTO MDI/MDIX - PoE Ports (RJ45): Port 1-2 compliance with 802.3af/at/bt
Ports 3-8 compliance with 802.3af/at
Power Supply: 123 W - Switching Capacity: 20 Gbps
- Power Supply: External Power Adapter (Output: 53.5 VDC / 2.43 A)
Consumption:
8.7 W (220/50 Hz. no PD connected)
144.1 W (220/50 Hz. with 123 W PD connected) - Dimensions: (WxDxH) 209 x 126 x 26 mm
- Transfer Method: Store-And-Forward
- Mac Address Table: 4K
- Packet Forwarding Rate: 14.88 Mpps
- Additional Features: “Compatible With IEEE 802.3af/at/bt Compliant PDs
Mac Address Auto-Learning And Auto-Aging
IEEE 802.3x Flow Control
802.1p/DSCP QoS
IGMP Snooping
PoE Auto Recovery (Ports 1-8)
Isolation Mode (Ports 1-4/5-8)
Priority Mode (Ports 1-2)
Extend Mode Button (Ports 1–4, Up to 250m PoE power supply and data transmission)” - Management: Unmanaged
- Environment: Operating Temperature: 0–40°C (32–104°F)
Storage Temperature: -40–70°C (-40–158°F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: TL-SG1210PP
Power Adapter
Installation Guide - Package Type: Retail
- Package Weight: 1.7500 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
5 in stock
TP-LINK (TL-SG1210PP) 10-Port Gigabit Desktop Switch with 6-Port PoE+ & 2-Port PoE++
£134.96 Add to basketQuick View -
£133.58
Description
Specification
- Rackmountable: Yes
- Managed: No
- Number of Ports: 16
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 16 x 10/100Mbps RJ45 Ports
2 x 10/100/1000Mbps RJ45 Ports
2 x Gigabit SFP Slots - PoE Ports (RJ45): 16 PoE+ 10/100Mbps RJ45 ports
Standard: 802.3at/802.3af compliant
PoE Ports: Port1- Port16
PoE Power Budget: 192W - Switching Capacity: 7.2Gbps
- Power Supply: “100-240V AC, 50/60Hz”
- Dimensions: 440 x 180 x 44 mm
- Mac Address Table: 8K
- Packet Forwarding Rate: 5.36Mpps
- Jumbo Frame: 10KB
- Additional Features: Extend Mode (Up to 250m PoE power supply and data transmission)
- Environment: Operating Temperature: 0C~40C (32F~104F)
Storage Temperature: -40C~70C (-40F~158F)
Operating Humidity: 10%~90%RH non-condensing
Storage Humidity: 5%~90%RH non-condensing - Package Type: Retail
- Package Weight: 2.9530 kg
- Warranty: Lifetime Warranty
- #Hide#POE: Yes
11 in stock
TP-LINK (TL-SL1218MP) 16-Port 10/100Mbps + 2-Port GB Unmanaged PoE Switch, 2 combo GB SFP Slots, 16-Port PoE, Rackmountable
£133.58 Add to basketQuick View -
£128.00
Description
Specification
- Rackmountable: Yes
- Managed: Smart
- Number of Ports: 16
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- Interface(s): 16 x 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX - PoE Ports (RJ45): Standard: 802.3 at compliant
PoE Ports: Port 1- Port 8
PoE Power Budget: 110W - Standards and Protocols: “IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p”
- Switching Capacity: 32Gbps
- Power Supply: “100-240VAC, 50/60Hz / PoE”
- Dimensions: 294 x 180 x 44 mm
- Mac Address Table: 8K
- Packet Forwarding Rate: 23.8Mbps
- Jumbo Frame: 9KB
- Additional Features: See Overview
- Quality of Service: Support Port-Based/802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control - Layer Features: L2 Features:
IGMP Snooping V1/V2/V3
Link Aggregation
Port Mirroring
Cable Diagnostics
Loop Prevention - VLAN: Supports up to 128 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN - Management: Web-based GUI
Easy Smart Configuration Utility - Environment: Operating Temperature: 0C~40C (32F~104F)
Storage Temperature: -40C~70C (-40F~158F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing - Package Contents: TL-SG1016PE
Power Cord
Installation Guide
Resource CD
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 2.4600 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
37 in stock
TP-LINK (TL-SG1016PE) 16-Port Gigabit Easy Smart Desktop/Rackmount Switch, 8-Port PoE+, Metal
£128.00 Add to basketQuick View -
£128.00
Description
Specification
- Rackmountable: Yes
- Managed: No
- Number of Ports: 16
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 16 x PoE+ 10/100 Mbps RJ45 Ports
2 x 10/100/1000 Mbps RJ45 Ports
1 x Combo Gigabit SFP Slot - PoE Ports (RJ45): Standard: 802.3at/802.3af compliant
PoE Ports: Ports 1–16
PoE Power Budget: 150 W - Switching Capacity: 7.2 Gbps
- Power Supply: “100–240V AC, 50/60 Hz
Max consumption:
12.71 W (220/50Hz. no PD connected)
172.8 W (220/50Hz. with 150 W PD connected)” - Dimensions: 440 x 180 x 44 mm
- Mac Address Table: 8K
- Packet Forwarding Rate: 5.36 Mpps
- Jumbo Frame: 10 KB
- Additional Features: Compatible With IEEE 802.3at/af Compliant PDs
Extend Mode (Up to 250m PoE power supply and data transmission)
Priority Mode
Isolation Mode
Mac Address Auto-Learning And Auto-Aging
IEEE802.3x Flow Control - Security: Physical Security Lock
- Management: –
- Environment: Operating Temperature: 0–50 °C (32–122 °F)
Storage Temperature: -40–70 °C (-40–158 °F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: TL-SL1218P
Power Cable
Installation Guide
Two mounting brackets and the fittings - Package Type: Retail
- Package Weight: 2.8000 kg
- Warranty: Lifetime Warranty
- #Hide#POE: Yes
Out of stock
TP-LINK (TL-SL1218P) 16-Port 10/100Mbps + 2-Port GB Unmanaged Rackmount PoE+ Switch, Combo GB SFP Slot, 16-Port PoE+
£128.00 Read moreQuick View -
£128.00
Description
Specification
- Rackmountable: No
- Managed: No
- Number of Ports: 16
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- Interface(s): 16 x 10/100/1000Mbps RJ45 Ports
AUTO Negotiation
AUTO MDI/MDIX - PoE Ports (RJ45): Standard: 802.3 af/at compliant
PoE Ports: Ports 1–16
Power Supply: 120 W - Switching Capacity: 32 Gbps
- Power Supply: External Power Adapter (Output: 53.5 VDC / 2.43 A)
- Dimensions: (WxDxH) 286 x 111.7 x 25.4 mm
- Transfer Method: Store-And-Forward
- Mac Address Table: “8K, Auto-learning, Auto-aging”
- Packet Forwarding Rate: 23.8 Mpps
- Additional Features: “Compatible With IEEE 802.3af/at Compliant PDs
Extend Mode Button (Ports 1–4, Up to 250m PoE power & data transmission)
Priority Mode Button (Ports 1–4)
Isolation Mode Button (Ports 1–7 / 8-14)
PoE Auto Recovery (Ports 1-16)
Mac Address Auto-Learning And Auto-Aging
IEEE 802.3x Flow Control
IGMP Snooping” - Quality of Service: 802.1p/DSCP QoS
- Environment: Operating Temperature: 0–40°C (32–104°F)
Storage Temperature: -40–70°C (-40–158°F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing - Package Contents: TL-SG116P
Power Adapter
Installation Guide - Package Type: Retail
- Package Weight: 2.2500 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
12 in stock
TP-LINK (TL-SG116P) 16-Port Gigabit Desktop Switch with 16-Port PoE+
£128.00 Add to basketQuick View -
£125.22
Description
Specification
- Rackmountable: No
- Managed: Smart
- Number of Ports: 10
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 8 x 10/100/1000Mbps RJ45
2 x Gigabit SFP - PoE Ports (RJ45): “8, up to 30 W”
- Bandwidth: 20 Gbps
- Standards and Protocols: “IEEE 802.3i, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab,
IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x” - Switching Capacity: 16 Gbps
- Power Supply: 12 VDC/1 A External Adapter
or
Power from PoE Source - Dimensions: (WxDxH) 209 x 126 x 26 mm
- Transfer Method: Store and Forward
- Mac Address Table: 8K
- Packet Forwarding Rate: 14.88 Mpps
- Jumbo Frame: 9 KB
- Additional Features: Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule - Quality of Service: 802.1p CoS/DSCP priority
8 priority queues
Queue Weight Config
Priority Schedule Mode
– SP (Strict Priority)
– WRR (Weighted Round Robin) - Layer Features: “L2+ Features:
16 IP Interfaces
Static Routing
DHCP Server
DHCP Relay
DHCP L2 RelayL2 Features:
Link Aggregation
Spanning Tree Protocol
Loopback DetectionL2 Multicast:
511 IPv4, IPv6 shared multicast groups
IGMP Snooping
Multicast VLAN Registration (MVR)
Multicast Filtering” - VLAN: VLAN Group
802.1Q tag VLAN
MAC VLAN: 12 Entries
Protocol VLAN
GVRP
Voice VLAN - Access Control: Support up to 230 entries
Time-Range
Time-based ACL
MAC ACL
IP ACL
IPv6 ACL
Combined ACL
Rule Operation
Policy Action
ACL Rules Binding
Actions for flows - Security: AAA
802.1X
IP/IPv6-MAC Binding
IP Source Guard
IPv6 Source Guard
DoS Defend
Static/Dynamic/Permanent Port Security
Broadcast/Multicast/Unicast Storm Control
Port Isolation
Secure web management through HTTPS with SSLv3/TLS 1.2
Secure Command Line Interface (CLI) management with SSHv1/SSHv2
IP/Port/MAC based access control - Management: “Omada App
Centralized Management (OC300/OC200/Omada Software Controller)
Cloud Access (OC300/OC200/Omada Software Controller)
Zero-Touch Provisioning
Web-based GUI
Command Line Interface (CLI) through telnet
SNMPv1/v2c/v3
SNMP Trap/Inform
RMON (1,2,3,9 groups)
SDM Template
DHCP/BOOTP Client
Dual Image, Dual Configuration” - .: CPU Monitoring
Cable Diagnostics
EEE
SNTP
System Log - Environment: “Operating Temperature: 0C~40C (32F~104F);
Storage Temperature: -40C~70C (-40F~158F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing” - Package Contents: TL-SG2210P
Power Adapter
Installation Guide
Rubber Feet - Package Type: Retail
- Package Weight: 1.3100 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
40 in stock
TP-LINK (TL-SG2210P V5) JetStream 10-Port Gigabit Smart Switch with 8-Port PoE+, 2 SFP Ports, Desktop/Wall Mount
£125.22 Add to basketQuick View -
£125.22
Description
Specification
- Rackmountable: Yes
- Managed: Smart
- Number of Ports: 16
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 16 x 10/100/1000 Mbps RJ45 Ports
2 x Gigabit SFP Slots - PoE Ports (RJ45): –
- Switching Capacity: 36 Gbps
- Power Supply: 100-240 V AC~50/60 Hz
Max Power Consumption: 12.3 W (220 V/50 Hz) - Dimensions: 440 x 180 x 44 mm
- Mac Address Table: 8K
- Packet Forwarding Rate: 26.8 Mpps
- Jumbo Frame: 9 KB
- Additional Features: Support Omada Hardware/Software/Cloud-Based Controller
Automatic Device Discovery
Batch Configuration
Batch Firmware Upgrading
Intelligent Network Monitoring
Abnormal Event Warnings
Unified Configuration
Reboot Schedule
ZTP (Zero-Touch Provisioning) - Quality of Service: L2/L3/L4 QoS and IGMP snooping
- Layer Features: L2 and L2+:
Link Aggregation
Spanning Tree Protocol
Loopback Detection
Flow Control
MirroringL3:
16 IPv4/IPv6 Interfaces
Static Routing
Static ARP
316 ARP Entries
Proxy ARP
Gratuitous ARP
DHCP Server
DHCP Relay
DHCP L2 Relay - VLAN: “VLAN Group
802.1q Tagged VLAN
MAC VLAN: 12 Entries
Protocol VLAN: Template 16, VLAN 16
GVRP
VLAN VPN (QinQ)
Voice VLAN” - Access Control: Time-based ACL
MAC ACL
IP ACL
Combined ACL
Packet Content ACL
IPv6 ACL
Policy
ACL apply to Port/VLAN - Security: IP-MAC-Port Binding
IPv6-MAC-Port Binding
DoS Defend
Static/Dynamic Port Security
Broadcast/Multicast/Unicast Storm Control
IP/Port/MAC based access control
802.1X
AAA (including TACACS+)
Port Isolation
Secure web management – HTTPS with SSLv3/TLS 1.2
Secure CLI management with SSHv1/SSHv2 - Management: “Web-based GUI
CLI through console port, telnet
SNMPv1/v2c/v3
SDM Template
DHCP/BOOTP Client
802.1ab LLDP/LLDP-MED
DHCP AutoInstall
Dual Image, Dual Configuration
CPU Monitoring
Cable Diagnostics
EEE
Password Recovery
SNTP
System Log” - Environment: “Operating Temperature: 0–40 C (32–104 F);
Storage Temperature: -40–70 C (-40–158 F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing” - Package Contents: TL-SG2218 Switch
Power Cord
Quick Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 2.5320 kg
- Warranty: Limited Lifetime
- #Hide#POE: No
Out of stock
TP-LINK (TL-SG2218) JetStream 16-Port Gigabit Smart Switch with 2 SFP Slots, L2/L3/L4 QoS, Fanless, Rackmountable
£125.22 Read moreQuick View
