Interface(s): 4 x 2.5G PON Ports 1 x 10 Gbps SFP+ Uplink Ports 1 x 10/100/1000 Mbps RJ45 Uplink Port 1 x RJ45 Console Port 1 x RJ45 MGMT Port 1 x Alarm Port (Reserved)
Button: Reset Button
Power Supply: “Dual Power Supplies AC: 100V~240V, 50/60Hz DC: -38.4V~-72V Power Consumption: Max. 58W”
Data Rates: Downstream: 2.5 Gbps Upstream: 1.25 Gbps
Wavelength: Tx: 1490 nm Rx: 1310 nm
Fiber Type: 9/125um SMF (Single Mode Fiber)
Distance: 20 km
Max. Splitting Ratio: 1:128
DHCP: DHCP Server DHCP Relay
Multi-Service: Multi-Service Traffic Identify and Rate Limit
QoS: IEEE 802.1p/DSCP QoS Voice VLAN Auto VoIP
Routing: Static Routing
Mulitcast: IGMP Snooping MLD Snooping
Security: ACL 802.1x Authentication ARP Inspection IP Source Guard
ONU Security: Rouge ONU Detection and Isolation Uplink and Downlink Data Encryption
Management: “OMCI: Standard OMCI Management Supported
DeltaStream 4-port Pizza-box GPON Optical Line Terminal
4 GPON Ports: Supports 1:128 splitting ratio for every port—up to 512 ONTs by one device.
High-Speed Uplink Ports: Provides 1x 10GE SFP+ port and 1x gigabit uplink port.
Redundant Dual Power Supplies: Carrier-class reliability with dual built-in AC+DC power supplies.
Complete L2 & Advanced L3 Functions: Satisfies the need for numerous commercial requirements.
Centralized Management: Via DeltaStream PON Management System (DPMS), SNMP, CLI, and WEB UI.
Advanced L2/L2+ Functions: Static Routing, IGMP Snooping, and more meet the requirement for different applications.
Free Centralized Management
Via DeltaStream PON Management System (DPMS)
Easy maintenance and centralized management makes your life a breeze. Configure and update all your devices at once via DeltaStream PON Management System (DPMS), SNMP, CLI and Web UI.
Compact Size, Flexible Deployment
Mount in a rack for flexible deployment with all your other products.
Constant Reliability Through Redundant Dual Power Supplies
Dual built-in AC and DC power supplies ensures carrier-class reliability.
*Actual network speed may be limited by the rate of the products Ethernet WAN or LAN port, the rate supported by the network cable, internet service provider factors, and other environmental conditions.
Advanced Features: Upstream and Downstream FEC Dynamic Bandwidth Allocation(DBA) support NSR/SR Up to 16 T-CONTs and 256 GEM Ports Optical power detection Dying Gasp Terminal Silent mechanism
Features: Practical Design for Hiding Cables Waterproof Design Easy to Install Suitable for Indoor or Outdoor Wall/Ceiling Mounting
Weight: 364g
Dimensions : 125 (diameter) x 130.47 x 45.7 mm
Compatibility: “Compatible with Most VIGI Cameras* *It is recommended to use with VIGI Camera to prevent compatibility issues, overload, and other problems. VJB-300 is not compatible with InSight S345ZI, InSight S445ZI.”
Interface(s): 8 x XGS-PON & GPON Combo Ports (SFP+) 2 x 40G QSFP+ Ports 2 x 10G SFP+ Ports 1 x RJ45 Management Port 1 x RJ45 Console Port 1 x Alarm Port
Button: Reset Button
Power Supply: “Dual Power Supplies: 2 AC, 2 DC or AC+DC, AC: 100V~240V, 50/60Hz DC: -38.4V~-72V Power Consumption: Max. 109.2W”
Data Rates: “GPON: Downstream: 2.5 Gbps, Upstream: 1.25 Gbps
